HK-EFP-A2202 2-ch forward direction SDI to fiber broadcast live shooting system

HK-EFP-A2202 2-ch forward direction SDI to fiber broadcast live shooting system

Overview:

HK-EFP-A2202 2-ch forward direction SDI to fiber broadcast live shooting system, 2ch forward+1ch reverse SDI to fiber broadcast live shooting includes a Camera Optic Adaptor and aOptic Base Station. The system transports 2ch 3G/HD-SDI signal from the camera to the Base Station, 1ch reverse 3G/HD-SDI, Genlock or BB/TC, intercom (Cameraend can be connected to professional 4-pin or 5-pin XLR headset, OB end can be connected intercom main station), tally(One color or two colors can be selected), 1ch reverse PGM audio,1ch 10/100M Ethernet, Remote camera power supply (14.6V DC up to 100 Watts). The system puts all of the signals needed for multi-camera 3G/HD-SDI production on an SMPTE hybrid cable, ensuring robust, trouble-free connectivity in any studio or remote production.

Because of its simple function, 4 bases can be combined into one Optic Base Station.

SONY EFP fiber system
4 Camera ends and 1x 1U rack Base end | 4 bases can be combined into one Optic Base Station.

Technical parameter list:

  Product Name   2-ch forward direction SDI to fiber broadcast live shooting system
  Product Model   HK-EFP-A2202
  SDI Connector   BNC 75 Ohm
  Optical Fiber   Single mode / Multimode, FC/SC/ST/LC, Duplex,
  Power Supply   DC 11V to 19V
  Power Consumption   <12W
  Dimension / GW   19” 1U standard rack mount at base end
  Working Environment   Working Temperature: -20°C to 55°C; Relative Humidity: 0 ~ 95% (no cold condensation)
  Warranty   2 Years

Features:

1) 2ch forward and 1ch reverse SDI
2) Handle all Pathological patterns
3) Automatic cable equalization to ensure signal integrity
4) 3G/HD/SD-SDI input auto recognition,support 270Mbit/s – 2.97Gbit/s according to SMPTE 424M, SMPTE 292M and SMPTE259M
5) Mic inputs with mute and pre-amps
6) Headphones with volume up or down
7) Remote control (Sony/ Panasonic/JVC/Ikegami/ Datavideo optional)
8) Tally LED+/- wet output or dry ContactClosure optional
9) V-mount or A-mount (Anton/Bauer)battery plate optional
10) Genlock or TC/BB is available
11) Reverse PGM/IFB audio optional
12) 10/100M Ethernet is optional
13) Remote camera power supply (14.6V DC up to 100 Watts), with insertion detection protection, Lemo SMPTE 304 or NeutrikOpticalCON DUO connector
14) SMPTE hybrid cable 200+m

Diagram:

diagram
Detailed benefits

Adapter to Base diagram:

SDI & Tally & Intercom from the Adapter to Base station over fiber system

SDI: 2ch forward + 1ch return
Tally: 1ch
BB/TC: 1ch
Intercom to main station: Balanced audio
Ethernet: 10/100M
PGM: 1ch
Remote power supply: Lemo SMPTE 304

Specifications:

General index

Work Temp-25°C to 55°C
Storage Temp-40°C to 85°C
humidity0 ~ 95% (non-condensing)

Camera Optic Adaptor
Input powerDC 11~19V
Power consumption<12W
Net weight1kg
Appearance size188mm*116mm*45mm (without V-mount / A-mount)

Optic Base Station
Input powerAC90~240V
Power consumption<12W
Net weight3kg
Appearance size19” 1U standard rack mount

Optical：

Wavelength1310nm / 1550nm / CWDM
Output Power-6~-1dBm
Rx sensitivity<-18dBm
Transmission DistanceRemote power 100W，SMPTE hybrid cable 200+m
Optical connectorDual LC/ST/FC

SDI input/output:

Signal formatSMPTE 424M, SMPTE 292M, SMPTE 259M
Data rate270Mbit/s- 1.48Gbit/s – 3Gbit/s
Cable EqualizationAutomatic cable EQ (Belden 1694A cable)250m @ 270Mbit/s, 140m @ 1.5Gbit/s, 80m @ 3Gbit/s
SDI interfaceBNC 75 Ohm

Genlock /TC / BB

Number of Channels1
Input/output impedanceBNC 75Ω (unbalanced)
Input/output voltage1.0Vp-p
Differential Gain< ±1.5%
Differential Phase< ±1%
SNR>60dB

Intercom:


Camera Optic Adaptor
Interface4pin XLR(Male) /5pin XLR(Female)/ 3.5mm headset jack
MicrophoneMic inputs with mute and pre-amps
Headphonewith volume up or down

Optic Base Station
Interface3pin XLR Female/Male: Party line audio for Clearcom / Altairaudio / Granitesound’s Intercom main station, or Line level balanced audio input and output
DB9(Male): Line level unbalanced audio input and output,

Tally:


Camera Optic Adaptor
Interface4pin or 3pin mini XLR
OutputDry Contact Closure or wet LED+/-
On: short or LED onOff: open or LED off

Optic Base Station
InterfaceDB9(Male)
InputDry Contact Closure or TTL
On: short to GND or TTL low Off: open or TTL high

Remote：


Camera Optic Adaptor
InterfaceSony’s 8-pin interface
DataRS422 /RS232/RS485

Optic Base Station
InterfaceSony’s 8-pin interface
DataRS422 /RS232/RS485

PGM:


Camera Optic Adaptor
Interface4pin XLR(Male) /5pin XLR(Female)/ 3.5mm headset jack
Headphonewith volume up or down

Optic Base Station
Interface3pin XLR Female: Line level balanced audio input

Ethernet：

Work modeFull duplex/half duplex
Data Rate10/100Mbps(AUTO)
connection terminalRJ45

All of our EFP-to-fiber systems are customizable.
